JK-SDE-90 High Shear Dispersing Emulsifier
Advantages:
1. A Working Capacity of 1L~30L (H2O) specially designed for pilot-plant experiment.
2. By replacing another agitator, the equipment can supply a different function such as Eumix (mixing), Hishear (dispersing, homogenizing, emulsifying), Jetmixers (Jet mixing) or PLM (Powder Liquid Mixing).
3. The equipment is equipped with a high-speed frequency converting motor, and is started up with frequency converting for self-protection, and the Rotation speed can be controlled and displayed.
4. Maximum working duration: 4 hour.
5. Quick coupling dispersing head, easy to be dismantled and replaced.
6. Modular design, flexible combination.
Cases of application:
1. Oil & Water emulsifying by a Hishear agitator
Pour the water phase into the Vessel, regulate the Rotation speed to 5,000rpm, and then add the oil phase, make the equipment run for 10 minutes to end the emulsifying process.
2. Xanthate gum dissolving by a Jetmixers agitator
Pour the xanthate gum into water, regulate the Rotation speed to 4,500rpm, and make the equipment run for 15 minutes to end the dissolving.
2. Pigment dispersing by an Eumix fluted disc agitator
Pour the pigment into water, regulate the Rotation speed to 3,000rpm, and make the equipment run for 15 minutes to end the dispersing.
Function:
Homogenizing/ emulsifying/ depolymerizing/ dispersing/ vaccine/ fat milk/ pesticide/ yoghurt/ textile accessory ingredient/ suspension/ fruit juice/ cell rupture/ oil & water emulsifying/ coal slurry/ cosmetics/ bitumen/ pigment/ essence
Working Capacity:5L-50L（H2O）
Technical parameters:
Power: 1500W
Voltage: 220V, 50Hz / 60HZ
Rotation speed range: 600~3600rpm Variable frequency
Speed display: digital display
Standard agitator: 90G
Optional agitators: 6 types, Click here to view
Medium-contacting parts material: 304/316L
Shaft sleeve material: PTFE
Working stand: Hydraulic lifting
Package: Wooden crate
Total weight: 30kg
Package size: Verify at purchasing
Accessories: Connecting line for transducer
Spares: Shaft sleeve
Optional parts for sale: Vessel installing flange
|
