JK-CFD-6A Crude Fat Determinator

JK-CFD-6A crude fat determinator is based on principles of Soxhlet extraction to determine the content of fat with the method of weight determination. That is make the fat soluble in organic solvents, with the solvent extraction method to separate the fat, and then dries, weighs to calculate the fat content. The JK-CFD-6A crude fat determinator has a reasonable design, stable performance, high precision, effort-saving and time-saving operation, the measurement result conforms to the national standards, each target and performance all reach the requirement of similar import product. The JK-CFD-6A crude fat determinator is an ideal equipment of measuring fat for food, fat, feed and so on.

Technical specification of JK-CFD-6A crude fat determinator:

1. Measurement scope: grain, feed, fuel oils and all kinds of fat products which have 0.5%-60% oil

2. Measurement sample: 6

3. Extraction time is adjustable,has time alarm function

4. Supply voltage: 220V±10V   Frequency: 50Hz

5. Electric heating power: 600W

6. Controlling temperature range: indoor temperature -100oC

7. Size: 550×320×626；

8.Weight: 23kg

JK-CFD-6A crude fat determinator mainly has three major part compositions of heating extraction, solvent recovery and cooling.When JK-CFD-6A crude fat determinator operates,it may adjust the heating temperature according to the reagent boiling point and the different ambient temperature, the test specimen soaks and extracts repeatedly in the extraction process, thus achieves the fast measurement goal.
