Use scale instruction booklet

一．Essential feature

1. Weighing/scaleinterval:20KG/10g,,40KG/10g;

2. Nominal unit: (KG), (LB), (jin), (OZ);

3. Working voltage: 3.0V, the lowest working voltage, 2.5V, LCD demonstrates“LO” the low electricity icon;

4. Automatic close-down: And zero condition non-pressed key operation/non-active status, 120 second automatic close-down;

5.  Starting demonstration: Starting LCD demonstrates at the same time 8888,3 seconds LED to lighten, when return-to-zero LED extinguishment;

6. Choice locking function: Long according to (the TARE key), LCD demonstrated“L_ON” expression locking function opening, after weight locking, LCD demonstrated that LOCK, LED long bright, the digit is stable; If long presses the TARE key (LCD to demonstrate that the L_OF expression locking function closure, this time weighing in the process LED not to be bright;

二．Pressed key definition

1. Starting/close-down key: According to this (the POWER key)   starting, starting closes down according to this POWER key;

2.  Skins the key/to reset the key/number lock key: (The TARE key)

to buckle according to this skins again, the entire measuring   range skins the reset, the locking key;

3.  The unit transforms the key: According to this (the UNIT key) the

Selection unit, its order is KG, LB, the jin, OZ in turn;

三．Important explanation

1. This aircraft is equipped with the starting time low voltage    examination, when the voltage is lower than the hypothesisvoltage to demonstrate that“LO” the low electricity icon, the reminder must replace the battery;

2. If the weight is lower than zero spot, demonstrated that“-”,

simultaneously demonstrated“TARE”, according to removes   simultaneously eliminates” TARE”/“-”;

3．For this product smooth use cuts must overload, the weight   overload picture demonstrates “O-LD”;

4.  Refuses to grasp the electronic scale outer covering to carry on

the weighing, can only allow to hold on the suspenders link   use

weighing;

5.  If the long time does not use, then should take out the battery,   because avoids the battery leaking the fluid to cause the   product damage.
